Introduction
BDP Series is a kind of automatic parking equipment. It is suitable for both commercial and residential parking purposes. It moves vertically & horizontally with the platform to park & retrieve car freely.
Galvanized platform with wave plate for better parking
Hydraulic cylinder with steel rope drive
Fast lifting and descending speed
Patented hydraulic variable frequency speed control
PLC control system with central power pack
Patented anti-falling frame protection
Hydraulic overloading protection
Safety Protection Devices
Photoelectric detection for height and entrance safety
Fixed style anti-falling frame device
Sound and light warning systems
Electromagnetic anti-falling device
Oil cylinder top limit switch device
Car blocking device on platform
Phase order and limit switch protection
Emergency sudden stop device
Overloading and voltage protection
Lifting and sliding combined locking device
Frequently Asked Questions
What is the maximum car weight the BDP system can handle?
The system supports a lifting capacity of 2000kg to 2500kg per platform, making it suitable for most sedans and SUVs.
What are the available vehicle dimensions for this system?
The system accommodates vehicles with maximum dimensions up to 5000mm in length, 1850mm in width, and heights of 1550mm or 2050mm.
Is the BDP Series suitable for outdoor installation?
Yes, it features a galvanized platform and powder coating finishing, and can be installed in multi-level, surface mount, or underground configurations.
What kind of safety mechanisms are in place to prevent accidents?
The system includes 13 safety features, including patented anti-falling frames, photoelectric sensors for entrance detection, emergency stop buttons, and hydraulic overload protection.
How is the parking system controlled?
The BDP Series utilizes a PLC control system and can be operated via IC Card, Remote Control, or manual buttons for user convenience.
What certifications does the system hold?
The system is fully certified with CE, ISO, and CCC standards, ensuring compliance with international quality and safety regulations.
